| Network standards |
IEEE802.3、 IEEE802.3u、 IEEE802.3ab、 IEEE802.3z、 IEEE802.3x、 IEEE802.3af/at、IEEE802.1p、IEEE802.1q、 IEEE802.1w、 IEEE802.1d、 IEEE802.1s |
| LED Indicator |
1*Link/Act or PoE LED indicator |
| 1*Link/1*Link/Act mode converting LED indicator |
| 1*PoE mode converting LED indicator |
| 1*PoE Max LED indicator |
| 1*Power LED indicator |
| 1*SYS LED indicator |
| Interfaces |
24*10/100/1000 Base-T Ethernet ports |
| 4*1000 Base-X SFP ports |
| 1*Console port |
| Transmission media |
Recommended: CAT5/5e UTP or better |
| Fan quantity |
2 |
| Level of protection |
Lightning protection for ports: 6kV |
| Lightning protection for power: 6kV |
| ESD: |
| Air discharge: ±10kV |
| Contact discharge: ±8kV |
| Forwarding mode |
Store-and-forward |
| Switch capacity |
56Gbps |
| Packet forwarding rate |
41.70Mpps |
| Buffer |
12Mb |
| MAC address table |
16K |
| Jumbo frame |
10K |
| PoE power supply management |
Support |
| PoE budget |
Single port: AF: 15.4W, AT: 30W |
| Whole device: 370W |
| Input voltage |
100-240V AC 50/60Hz |
| Power consumption |
Full load: ＜432W |
| Empty load: ＜23W |
| Dimension |
440.0mmx284.0mmx44.0mm |
| Mounting |
Desktop mounting: support |
| Wall mounting: support |
| Rack mounting:non-support |
| Energy Efficient |
Support |
| Environment |
Operating temperature: 0°C - 45℃ |
| Storage temperature: -40°C - 70°C |
| Operating humidity: (10% - 90%) RH, non-condensing |
| Storage humidity: (5% - 90%) RH, non-condensing |
| Certification |
FCC、CE、RoHS |
| L3 Features |
Supports VLAN-based routing |
| Supports IPv4/IPv6 static routing |
| Supports static ARP |
| PoE power supply management |
Supports port PoE configuration and power supply with priority |
| Supports PoE over-temperature protection |
| Supports PoE scheduled management |
| Supports intelligent management and PoE-powered device detection |
| (port status, power assignment and PoE-powered device status) |
| Security features |
ARP receiving limit |
| Unknown MAC address discard |
| DoS attack defense |
| 802.1x security authentication |
| Radius security authentication |
| VLAN |
IEEE 802.1Q VLAN |
| VLAN Layer-3 interfaces |
| Supports three port modes: Access, Trunk and Hybrid |
| DHCP Server |
DHCP Relay |
| DHCP Snooping |
| Supports Option 82 policy configuration |
| Port aggregation |
Static aggregation |
| LACP dynamic aggregation |
| Spanning tree |
IEEE 802.1d STP (Spanning Tree Protocol) |
| IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) |
| IEEE 802.1s MSTP (Multiple Spanning Tree Protocol) |
| Supports edge port |
| Supports BPDU statistics |
| Multicast |
IGMP Snooping V1/V2/V3 |
| Supports port fast leave |
| Port Mirroring |
Supports N: 1 port mirroring |
| Quality of Service |
SP (Strict Priority) |
| SWRR (Simple Weighted Round Robin) |
| WRR (Weighted Round Robin) |
| Supports 802.1p port trust mode |
| Supports DSCP port trust mode |
| Supports a maximum of 8-queue service quality mapping |
| ACL |
Supports MAC ACL and IP ACL |
| Loading and upgrade |
Supports FTP/TFTP/HTTP upgrade |
| Supports configuration import and export |
| Management and maintenance |
Supports Telnet, Console |
| Supports SNMP V1/V2/V3 |
| Supports WEB management and maintenance |
| Supports Ping/IPv6/Tracert/Connection Detection |
| CPU Monitoring and memory monitoring |
