Model

CPE6S

Dimensions

193*109*61mm

Deployment

Pole/Wall Mount

Application Scenarios

PtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance

Frequency Range

5GHz

Compliant Standards

IEEE 802.11a/n/ac

Private TDMA Protocol

ipMAX

Maximum Wireless Rate

867Mbps

Interfaces

4*10/100Mbps Ethernet Port

Antennas Gain

12dBi

Antenna Beamwidth

Horizontal: 30° Vertical: 30° Elevation: 30°

Reset Button

1

Power Consumption

4.7W

Waterproof Level

IP65

LED indicator

Power,PoE/LAN1,LAN2,LAN3,LAN4LED1,LED2,LED3

Power Method

12V1A Passive PoE
12V 1A DC

Lightning Protection

6000V

PoE 802.3af/at

/

Passive PoE

Passive power over ethernet via PoE/LAN (+4,5pins; -7,8pins ) up to 60 meters
Voltage range: 11-13V DC

Receive sensitivity

11a 6Mbps -92dBm±1.5dBm
11n MCS7 HT20 -72dBm±1.5dBm
11ac MCS9 HT80 -64dBm±1.5dBm

Package Contents

1*5GHz 12dBi ipMAX ac Outdoor CPE
1*Power adapter
1*PoE Injector
1*Quick Installation Guide

Operating Temperature

-30℃ ~ 60℃

Storage Temperature

-40℃ ~ 70℃

Operating Humidity

10%~90% non-condensing

Storage Humidity

10%~90% non-condensing

Default login IP

192.168.2.1

Default Login Username

admin

Default Login Password

admin

Certifications

FCC/CE/RoHS
