System
|
| Main Processor |
Quad-core embedded processor |
| Operating System |
Embedded LINUX |
| Audio and Video |
| IP Camera Input |
8 Channel |
| Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
HDMI: 3840 × 2160 , 1920 × 1080 , 1280 × 1024, |
| 1280 × 720 , 1024 × 768 |
| VGA: 1920 × 1080 , 1280 × 1024, |
| 1280 × 720 , 1024 × 768 |
| Decoding Capability |
4-ch@8MP(30fps), 16-ch@1080P(30fps) |
| Multi-screen Display |
8CH: 1/4/8/9 |
| 16CH: 1/4/8/9/16 |
| 32CH: 1/4/8/9/16/25/36 |
| OSD |
Camera title, Time, Camera lock, Motion detection, Recording |
| Recording |
| Compression |
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG |
| Resolution |
12MP with 15fps, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1, CIF with 30fps |
| Bit Rate |
16Kbps ~ 20Mbps Per Channel |
| Record Mode |
Manual, Schedule (Regular, MD(Motion Detection) , Alarm, IVS), Stop |
| Record Interval |
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Alarm Out, Video Push, Email, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering |
| Alarm input |
4 Channel |
| Relay Output |
2 Channel |
| Playback and Backup |
| Sync Playback |
8CH: 1/4/9 |
| 16/32CH: 1/4/9/16 |
| Search Mode |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device/Network |
| Third-party Support |
| Third-party Support |
Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more |
|
|
| Interface |
1 RJ-45 Port (10/100/1000Mbps) |
| PoE |
N/A |
| Network Function |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4IP |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android |
| Interoperability |
ONVIF 2.4, SDK, CGI |
| Storage |
| Internal HDD |
2 SATA III Ports, Up to 10 TB capacity for each HDD |
| eSATA |
N/A |
| Auxiliary Interface |
| USB |
2 USB Ports (1 Rear USB 3.0 , 1 Front USB 2.0 ) |
| RS232 |
1 Port, for PC Communication and Keyboard |
| RS485 |
1 Port, for PTZ Control |
| Electrical |
| Power Supply |
Single, DC12V/4A |
| Power Consumption |
<9.5W (Without HDD) |
| Fan |
Smart fan, automatically adjust running speed |
| Environmental |
| Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
| Construction |
| Dimensions |
1U, 375mm x 281.5mm x 56mm ; |
| (14.8" x 11.1" x 2.2") |
| Net Weight |
1.6kg (3.5 lb) (without HDD) |
| Gross Weight |
3.2kg (7.1 lb) (without HDD) |
| Certifications |
| CE |
EN55022, EN55024, EN50130-4, EN60950-1 |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| UL |
UL 60950-1 |
